Metal Stud Homes

Introduction



Metal stud homes, also known as steel frame homes, are becoming increasingly popular in the construction industry due to their numerous advantages. Metal stud homes can be used in a variety of settings, including residential, commercial, and industrial. They are ideal for areas with extreme weather conditions or high risk of fires. Additionally, they can be used in areas with limited space, as metal studs take up less room than traditional wood framing.Metal stud homes are suitable for a variety of people, including those who are environmentally conscious, those who want a durable and low-maintenance home, and those who want a customizable and versatile design. They are also a good choice for those who want to invest in a long-term, cost-effective housing solution.





Specifications for metal frame house construction
Main Steel	Q355, Q345, Q235, Q345B, Q235B etc.
Column & Beam	Welded or Hot rolled H-section
Secondary Frame	Hot Dipped Galvanized Purlin, Knee brace, Tie Rod, Brace, Vertical and Horizontal Support
Wall and Roof	Material: EPS Sandwich Panel /Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / Pu Sandwich Panel /Corrugated Steel Sheet
Door	Rolled up door, Sliding door or sandwich panel door, can be customized
Window	Plastic steel or Aluminum alloy window, can be customized
Surface treatment	Hot dip galvanized or painted



Working Procedure



1. Cutting

Use CNC Flame Cutting Machine



2. Assembling

Use H Beam Assembling Machine



3. Submerged arc welding

Use H-Beam Welding Machine



4. Straightening

Use Vertical Straightening Machine



5. Welding

Use Carbon Dioxide arc welding



6. Ultrasonic flaw detection



7. Shot blasting

Use H sectiong steel shot blasting derusing machine



8. Painting

Use High-pressure airless spraying



Some of the benefits of metal stud homes include:

Durability: Metal stud homes are incredibly durable and can withstand extreme weather conditions such as hurricanes, earthquakes, and tornadoes. The steel frame is resistant to moisture, mold, and fire, making it an ideal choice for areas prone to natural disasters.

Energy Efficiency: Metal stud homes are highly energy-efficient as they allow for superior insulation compared to traditional wood frame homes. This can result in lower energy bills and a more comfortable living environment.

Eco-Friendly: Metal stud homes are also environmentally friendly as steel is a recyclable material. Additionally, the use of metal studs eliminates the need for trees to be cut down, which helps to reduce deforestation.

Versatility: Metal stud homes can be designed in a wide range of styles, from traditional to modern, and can be customized to meet the specific needs and preferences of the homeowner. Steel frames can also support large windows and doors, allowing for ample natural light and ventilation.

Cost-Effective: While the initial cost of a metal stud home may be higher than a traditional wood frame home, the long-term cost savings can be significant. The durability and energy efficiency of the steel frame can result in lower maintenance costs and utility bills.



Quotation and Design Requirements



We need to get the below design Loads (very important) for the precise quotation and designing.

1. Snow load:

2. Wind load:

3. Seismic magnitude:

4. Middle Column allowed or not:

5. Project location:

6. Length (side wall, m):

7. Width (end wall, m):

8. Wall Height (eave, m):

9. Mezzanine or not? And usage:



Our Factory



In less than a decade, LUTUO has established a production base spanning across 70,000 ㎡ and has expanded its business scope to include various types of structure warehouses such as steel warehouse buildings, multi-story buildings, industrial residential buildings, steel frame prefab homes, container houses, frame structures for large equipment, and more. Additionally, LUTUO specializes in the construction of multi-story Light Gauge Steel Frame Houses, mobile portable container houses, and prefabricated expandable container houses. The company has also been recognized for its commitment to quality, having obtained ISO9001:2000 International Quality System Certification.





Overseas Cases

The Philippines portal frame warehouse: size: 30mx20mx6m





Packaging & Shipping



We use steel pallet to package, it is easy to load and unload! All the material are to be packed into the loading pallet, and use 40ft HQ shipping container for loading.





FAQ

When constructing metal stud homes, there are several important considerations to keep in mind. These include:

Building Codes: It is important to comply with local building codes when constructing metal stud homes. Building codes dictate various aspects of the construction process, including the minimum thickness and spacing of the steel studs, as well as the type of insulation and fireproofing required.

Foundation: The foundation for a metal stud home must be designed to support the weight of the steel frame. This may require additional reinforcement, such as concrete footings or piers.

Steel Studs: The steel studs used in metal stud homes should be made from high-quality, galvanized steel. They should be spaced and sized according to local building codes and the design of the home.

Insulation: Proper insulation is critical in metal stud homes, as steel is a good conductor of heat and cold. The insulation should be designed to fit snugly between the studs and should meet local building code requirements for energy efficiency.

Fireproofing: Metal stud homes should be fireproofed to ensure safety in the event of a fire. This may include the use of fire-resistant drywall or spray-on fireproofing materials.

Electrical and Plumbing: Electrical and plumbing systems should be installed by licensed professionals to ensure they meet local codes and are safe and functional.

Finishes: The finishes used in metal stud homes should be chosen carefully to ensure they are compatible with the steel frame. For example, drywall should be installed using specialized screws designed for use with steel studs.

By keeping these considerations in mind, metal stud homes can be constructed safely and efficiently, resulting in a durable and energy-efficient home.
