Construction Reinforcing Mesh
10x10 concrete reinforcing welded wire mesh is also called Construction Reinforced Concrete Mesh, Concrete Reinforcing Mesh, Welded Steel Bar Mesh, Steel Concrete Mesh.
Product Introduction
Product Description
1. 10x10 Construction Reinforcing mesh introduction:
10x10 concrete reinforcing welded wire mesh is also called Construction Reinforced Concrete Mesh, Concrete Reinforcing Mesh, Welded Steel Bar Mesh, Steel Concrete Mesh.
10x10 concrete reinforcing welded wire mesh is longitudinal reinforcement and transverse reinforcement were arranged in a certain interval and at right angles to each other, all the intersections are welded together.
2. 10x10 Construction Reinforcing mesh material:
10x10 concrete reinforcing welded wire mesh is welded form superior low carbon steel wire and then galvanized and PVC coated.It features smooth surface, uniform mesh, high stability and great corrosion resistance.
1-Electro galvanized mesh(welded before galvanized, welded after galvanized)
2-Hot-dipped galvanized mesh(welded before galvanized, welded after galvanized)
3-PVC coated mesh(wire diameter. of PVC is about 0.4mm)
Galvanized welded mesh has a good resistance to corrosion. Zinc coating can reach 200g/m2.
3. 10x10 Construction Reinforcing mesh advantages:
1. Lower the cost of the project.
2. Speed up the construction progress.
3. Ensure the quality of the project.
4. Anti-cracking performance, etc.
Specification
10x10 Construction Reinforcing meshspecification:
NO. | Types | Wire Spacing | Wire Diameter | Sheet Dimensions /m | Weight Per Sheet /kg | ||
Main /mm | Cross /mm | Main /mm | Cross /mm | ||||
1 | A98 | 200 | 200 | 5 | 5 | 2.15x5.00 | 16.7 |
2 | A142 | 6 | 6 | 24.1 | |||
3 | A193 | 7 | 7 | 32.8 | |||
4 | A252 | 8 | 8 | 43.0 | |||
5 | A393 | 10 | 10 | 67.1 | |||
6 | B503 | 100 | 200 | 8 | 8 | 64.7 | |
7 | B785 | 10 | 10 | 89.1 | |||
8 | A98' | 200 | 200 | 5 | 5 | 1.80x3.00 | 8.3 |
9 | A142' | 6 | 6 | 12.0 | |||
10 | A252' | 8 | 8 | 1.75x3.00 | 21.0 | ||
11 | A393' | 10 | 10 | 32.9 | |||
12 | Q92 | 150 | 150 | 4.2 | 4.2 | 2.15x5.00 | 15.9 |
13 | Q131 | 5 | 5 | 22.5 | |||
14 | Q188 | 6 | 6 | 32.4 | |||
15 | Q257 | 7 | 7 | 39.7 | |||
16 | R92 | 150 | 250 | 4.2 | 4.2 | 12.8 | |
Note: | |||||||
Product Detail For Construction Reinforcing Mesh
Assortment
10x10 Construction Reinforcing mesh producing process:
* Welded Stainless Steel Wire Mesh Panels
* Hot-dipped and Electro Galvanized Welded Mesh Panels
* PVC-coating/plastic-soaked Welded Mesh Panels
* Concrete reinforcement wire mesh panel
Feature
10x10 Construction Reinforcing mesh feature:
A. Light weight( 1/4 of the same reinforcement weight)
B. High tensile strength (approximately twice the load of the same reinforcement)
C. Anti-corrosion and durability
D. Anti-static
E. Non-conductive, will not produce sparks when cutting, especially for high gas region
F. Non-combustible (high thermal insulation)
G. Easy cutting ( avoid damage the cutting head and available)
H. Non-magnetic
Application
10x10 Construction Reinforcing mesh application:
It is widely used in the industry, agriculture, aquaculture, building, communication and transportation and mineral extraction, etc. It also finds application in shields on machinery or equipment, wire fence for livestock or flowers and trees, fence for protecting windows, fence for pathways, poultry cage, basket for holding eggs, foodstuff basket, paper basket or decorative fields in home or office
Packaging & Shipping
10x10 Construction Reinforcing mesh packing:
It is inside with plastic film and packed with water-proof paper, then pallet package,or according to customer's requirements.
FAQ
1.Q: Why choose us?
A: We are an iron and steel enterprise integrating industry and trade, Our company have been in steel business for more than ten years, we are internationally experienced, professional, and we can provide variety of steel products with high quality to our clients
2.Q: Can provide OEM/ODM service?
A: Yes. Please feel free to contact us for more details discuss.
3.Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
4.Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
5.Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
6.Q: Can you provide sample?
A: Yes, for regular sizes sample is free but buyer need to pay freight cost.
7.Q: How can I get a quotation from you ?
A: You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager. And you can also find our contact information on contact page.
